Location estimate

La Massana

La Massana · Andorra

Approximate location reference—not a rooftop, property or survey point.

Seasonal average-day estimates

Selected capacity 1 kWp

Showing the original estimates at 1 kWp. JavaScript is needed only to change capacity; source values and panel settings remain available below.

Changing capacity rescales my existing estimates. It does not recalculate their orientation, shading, equipment or loss assumptions.

Estimated average daily electricity for 1 kWp, in kWh/day, averaged over each season.

Summer

6.76

kWh/day

Autumn

3.58

kWh/day

Winter

2.42

kWh/day

Spring

5.38

kWh/day

Shared scale: 0–7.00 kWh/day.

I apply the same capacity factor to every season, so their proportions stay unchanged. The shared visual scale adjusts with capacity. To compare different system sizes, use the displayed kWh/day values.

This is illustrative scaling, not a site-specific production prediction.

Source basis and scaling limits

Original seasonal average-day estimates for La Massana, in kWh/kWp/day.

I calculate the scaled results from the original seasonal values and round the final energy results to two decimal places. Exceptionally large values may appear in approximate scientific notation; the full results, rounded to two decimal places, remain available here.

Original source values and selected-capacity calculation
SeasonRecorded kWh/kWp/dayExact selected-capacity result · kWh/day
Summer 6.76 6.76 × 1 kWp = 6.76 kWh/day
Autumn 3.58 3.58 × 1 kWp = 3.58 kWh/day
Winter 2.42 2.42 × 1 kWp = 2.42 kWh/day
Spring 5.38 5.38 × 1 kWp = 5.38 kWh/day

Ordinary calculations wrap onto two lines. Exceptionally long calculations can be scrolled within their labelled region.

Full results rounded to two decimal places

These preserve every whole-number digit. Exceptionally long values can be scrolled horizontally inside each labelled result.

Summer · kWh/day
6.76
Autumn · kWh/day
3.58
Winter · kWh/day
2.42
Spring · kWh/day
5.38

The original values remain available without JavaScript. Energy always uses kWh/day, including when capacity is entered in MWp. Changing units preserves the same physical capacity.

These are seasonal average-day estimates, not annual totals or installation sizing. Changing capacity does not revisit the assumptions used in my original estimates.

Detailed site analysisExplore historical generation and system configurations for your own project or your clients in the profileSOLAR app.

Year-round panel setup

Schematic catalogue setting — Year-round fixed panel setup: tilt 37 degrees above horizontal; facing South. Direction is illustrative; exact azimuth not recorded.NESW
Year-round fixed panel setup · schematic
Tilt from horizontal
37°
Facing direction
South

Catalogue direction; exact azimuth not recorded. The facing direction is illustrative.

Suggested seasonal tilts

Tilt from horizontal · facing direction

Summer
Jun, Jul, Aug
27°South
Autumn
Sep, Oct, Nov
47°South
Winter
Dec, Jan, Feb
57°South
Spring
Mar, Apr, May
35°South

The seasonal electricity figures do not model gains from switching between these settings.

About this orientation

This schematic shows the year-round panel tilt and facing direction for La Massana, Andorra.

For the year-round panel tilt, I used a simplified solar-noon calculation. This gives a broad starting point for considering a fixed panel angle at the location.

I weighted the daily angles by their share of estimated output. Read how I calculated panel tilt.

The panel shows tilt above horizontal on a fixed compass. North stays at the upper right in this projected view. Schematic only—not roof geometry, an installation drawing or a selected practical design.

Year-round and seasonal panel angles are separate estimates. Changing capacity rescales the existing energy values; it does not recalculate output for a different angle or facing direction.

Seasonal orientation diagrams

These show the separate seasonal settings above. Changing capacity does not change these angles or recalculate energy for a different orientation.

Summer

Schematic catalogue setting — Summer panel setup: tilt 27 degrees above horizontal; facing South. Direction is illustrative; exact azimuth not recorded.NESW
Summer panel setup · schematic

27° tilt · South

Illustrative direction; exact azimuth not recorded.

Autumn

Schematic catalogue setting — Autumn panel setup: tilt 47 degrees above horizontal; facing South. Direction is illustrative; exact azimuth not recorded.NESW
Autumn panel setup · schematic

47° tilt · South

Illustrative direction; exact azimuth not recorded.

Winter

Schematic catalogue setting — Winter panel setup: tilt 57 degrees above horizontal; facing South. Direction is illustrative; exact azimuth not recorded.NESW
Winter panel setup · schematic

57° tilt · South

Illustrative direction; exact azimuth not recorded.

Spring

Schematic catalogue setting — Spring panel setup: tilt 35 degrees above horizontal; facing South. Direction is illustrative; exact azimuth not recorded.NESW
Spring panel setup · schematic

35° tilt · South

Illustrative direction; exact azimuth not recorded.

Historical hourly-by-season solar output chart for La Massana, Andorra. View larger
Original chart units: hourly average electricity output in kWh per kW of installed solar PV.

Hourly electricity pattern for La Massana, Andorra

Hourly profiles by season — La Massana, Andorra · 2021

This chart shows how average electricity output varies through the hours of the day in each season. I have kept its original per-capacity basis: changing the capacity slider does not change this chart.

2021 is the method’s reference year, not verified year coverage for every point in this historical chart.

The cards above show seasonal average-day energy; this chart shows the hourly pattern. View the year-round panel setup.

Historical hourly chart

Hourly profiles by season — La Massana, Andorra · 2021

Swipe to pan, or focus the chart and use arrow keys.

Original chart units: hourly average electricity output in kWh per kW of installed solar PV.

This chart shows how average electricity output varies through the hours of the day in each season. I have kept its original per-capacity basis: changing the capacity slider does not change this chart.

The cards above show seasonal average-day energy; this chart shows the hourly pattern.

2021 is the method’s reference year, not verified year coverage for every plotted point.

Enlargement is limited to the original image resolution.

Row-spacing planning

Planning solar-panel row spacing in La Massana

Explore the space between parallel panel rows at one assumed winter-solstice solar-noon position.

Example: 2 m panel surface length, recorded year-round tilt and no added margin. Enable JavaScript to change these inputs.

Row pitch including margin

≈ 4.3 m

Proportional side viewDesign sun: ≈ 24° above horizontal
Row 1 Row 2 Clear gap Added margin: 0 m Row pitch including margin
  • Sunlight ray
  • First row’s ground shadow
  • Shadow endpoint
Calculated clear gap
≈ 2.7 m
Added margin
≈ 0 m
Gap including margin
≈ 2.7 m
Panel horizontal footprint
≈ 1.6 m
Panel vertical rise
≈ 1.2 m
Pitch before margin
≈ 4.3 m

Simplified level ground, equator-facing cross-section. Approximate Northern Hemisphere winter solstice at solar noon (day 355). The separate recorded facing direction is not an input.

One sun position, not a complete site-shading assessment. A geometric zero gap does not establish adequate installation, access or maintenance clearance.

Detailed inputs and unrounded results

More digits retain calculation precision; they do not imply greater model accuracy. Pitch including margin is pitch before margin plus the added margin, including when that margin is zero.

Panel surface length
2 m
Tilt up from horizontal
37°
Added margin
0 m
Latitude from the catalogue
42.548400000000000000° (Northern Hemisphere)
Panel horizontal footprint
1.5972710200945857 m
Panel vertical rise
1.2036300463040965 m
Calculated clear gap
2.703166616001337 m
Pitch before margin
4.300437636095923 m
Gap including margin
2.703166616001337 m
Row pitch including margin
4.300437636095923 m
Design solar elevation
24.001817153186348°
How this spacing estimate is calculated

I calculate this example at approximate winter solstice and solar noon for the location’s hemisphere. Tilt is measured up from horizontal and panel length is measured along the tilted module surface.

δ = 23.45° × sin(360° × (day − 81) ÷ 365); α = asin(sin(latitude) × sin(δ) + cos(latitude) × cos(δ)).

Rise = length × sin(tilt). Footprint = length × cos(tilt). Clear gap = rise ÷ tan(α). Row pitch = footprint + clear gap. The optional margin is added to the gap and pitch.

The calculated clear gap is the horizontal distance from the first panel’s high edge to its shadow endpoint. Any added margin then extends to the next row. Pitch is measured between corresponding leading edges, not just across the clear gap. The target is no geometric shadow at that one simplified solar-noon design instant.

The cross-section assumes parallel, equator-facing rows and a solar-noon ray perpendicular to them. The method ignores azimuth error and does not use the separate facing direction recorded for this location.

Terrain, mounting height, module thickness, obstructions, structural loads and regulations are outside this simplified geometry. A qualified designer should verify a real installation.

Detailed site analysisExplore historical generation and system configurations for your own project or your clients in the profileSOLAR app.

Solar context for La Massana

Read this location context alongside the calculation method and limitations; installation guidance is not a site-specific assessment.

La Massana's mountain setting makes the view of the sun an important part of using its solar resource. Valleys, wooded slopes and the surrounding skyline can produce very different conditions on individual roofs, especially when the sun is low.

Read the full article

For each 1 kW of rated panel capacity, our estimated average daily energy is 6.76 kWh/day in summer, 5.38 in spring, 3.58 in autumn and 2.42 in winter. Summer offers the strongest contribution in this comparison. The figures describe seasonal averages, so a winter heating requirement should not be compared with the summer figure alone. Our year-round fixed-panel reference is 37° up from horizontal, facing South. It provides a broad solar reference. A roof's existing pitch, nearby buildings and the mountain horizon still shape the practical arrangement; warmer weather alone does not make a panel more efficient. The Valira del Nord and the Arinsal river give La Massana a distinctive valley structure. At the Grau de la Grella, the historic route follows a confined, rocky part of the Valira corridor. That contrast between a narrow passage and a more open developed valley floor is useful context when considering how much sky a roof can see. An assessment can begin with the building already under consideration, checking its usable surface and safe access. Snow, cloud and local obstruction may reduce individual days' generation. The catalogue supports a seasonal comparison without assuming that every valley property has an equally open horizon.

Topography around La Massana

These landscape descriptions provide general context. The calculations do not model terrain, obstructions, shading or property suitability.

La Massana lies within the Pyrenean valley landscape of Andorra. The Valira del Nord and the Arinsal river meet in a landscape of developed valley ground, steep slopes and forest. Fir woodland is a characteristic part of the parish's mountain environment.

Read the full topography description

The Grau de la Grella is a particularly clear example of the valley's changing form. The old route beside the Valira del Nord passes through a narrow rocky section, where the path was cut into the slope. More open stretches elsewhere in the valley have a different relationship with the surrounding ridges. For solar panels, these differences matter most through the actual horizon seen from the mounting position. A roof can clear neighbouring buildings while still losing direct sunlight behind a ridge. Trees and the shape of the valley may also create different morning and afternoon conditions. Existing roads, buildings and watercourses occupy the lower ground. Its apparent flatness does not identify land for a new installation. A local roof and horizon assessment keeps the solar comparison connected to the developed premises while respecting the river corridor and wooded slopes.

Technical location reference

Approximate map point used for La Massana, Andorra

This coordinate is the calculation reference for La Massana, Andorra. Extra decimal places do not make it a rooftop, property or survey point.

Coordinates and precision
Map coordinate
42.548400000000000000, 1.511700000000000000
Originally displayed coordinate
lat42.5484 / long1.5117

How the estimate works

How this La Massana estimate was calculated

Here is how I calculated the location estimate for La Massana, Andorra.

Read how all Location estimates work

Source and scope

I calculated these location estimates using hourly NASA POWER solar-resource data, with 2021 as the reference year. The seasonal figures show estimated daily electricity production averaged over each season, on a common panel-capacity basis.

The figures are calculated estimates, not measured output or a new NASA request while you browse.

Reference period and source details

The reference year describes the intended input period; complete source-year coverage is not established for every historical result. Read the technical questions about source data and downloads.

NASA POWER project reference

The data was obtained from National Aeronautics and Space Administration (NASA) Langley Research Center's Prediction Of Worldwide Energy Resources (POWER) project funded through the NASA Earth Science Division.

This source reference does not imply NASA endorsement.

Use the result carefully

What this La Massana Location estimate includes and leaves out

Use the La Massana figures for broad location context, with the following boundaries in mind.

  • These catalogue estimates are informational; they do not establish a site-specific production result.
  • The location is an approximate reference, not a property, rooftop or survey coordinate.
  • The energy figures support broad location comparisons; they are not a generation guarantee or detailed system design.
  • The seasonal cards show average-day energy. An hourly chart, where available, shows a different view of the daily pattern.
  • Distance and clearance between rows require panel dimensions, mounting height, terrain, acceptable shading and a project-specific design.
