Phetchabun, Thailand presents a highly favorable location for year-round solar photovoltaic energy generation. Located in the tropics at coordinates 16.7839°N, 101.2466°E, this region benefits from consistent sunlight throughout most of the year, with seasonal variations characterized primarily by wet and dry periods rather than the dramatic temperature and daylight changes experienced in temperate climates.

Seasonal Solar Energy Production

The solar energy output at this location demonstrates excellent consistency across all seasons. Winter emerges as the peak production period, generating 5.85 kWh per day per kilowatt of installed solar capacity. Spring follows closely with 5.67 kWh/day per kW, while summer produces 5.44 kWh/day per kW. Autumn shows the lowest output at 4.94 kWh/day per kW, though this still represents strong production levels. The optimal months for solar generation align with Thailand's cool, dry season from November through February, when skies are typically clearest and atmospheric conditions most favorable for solar radiation. The slight dip in autumn production likely corresponds with the end of the rainy season when cloud cover and atmospheric moisture remain elevated.

Optimal Panel Configuration

For maximum year-round energy production at this Phetchabun location, solar panels should be installed at a fixed tilt angle of 17 degrees facing south. This angle has been calculated by analyzing daily solar elevation angles at this specific latitude, determining optimal panel positioning for each day, and weighting these angles according to solar irradiance data while accounting for Earth's elliptical orbit around the sun.

Environmental and Weather Challenges

Several significant local factors could potentially impede solar production at this location, requiring careful consideration during installation planning. Monsoon Season Impact: Thailand's monsoon season, typically occurring from May through October, brings heavy rainfall and increased cloud cover. Extended periods of overcast skies can substantially reduce solar output during these months. The seasonal production data reflects this challenge, with autumn showing the lowest generation figures as the rainy season concludes. High Humidity and Dust Accumulation: The tropical climate creates persistently high humidity levels, which can lead to faster accumulation of dust, pollen, and organic matter on panel surfaces. This buildup reduces light transmission and decreases efficiency over time. Tropical Storms and Severe Weather: The region may experience tropical storms or typhoons, particularly during monsoon season, which can damage installations or create debris that blocks panels.

Preventative Measures for Optimal Performance

Several installation strategies can help maximize energy production despite these environmental challenges:

• Enhanced Drainage Systems: Install robust drainage around panel arrays to prevent water pooling and ensure proper runoff during heavy rains
• Regular Cleaning Protocols: Implement frequent panel cleaning schedules, particularly during and after the rainy season when organic debris accumulation peaks
• Elevated Mounting Systems: Use elevated mounting structures to improve air circulation around panels, reducing humidity-related issues and allowing better water drainage
• Storm-Resistant Hardware: Employ reinforced mounting systems and hardware designed to withstand high winds and severe weather events
• Vegetation Management: Maintain clear zones around installations to prevent shading from rapidly growing tropical vegetation

Despite these challenges, Phetchabun's location offers excellent potential for solar energy generation. The consistent tropical sunlight and relatively minor seasonal variation in output make it well-suited for reliable renewable energy production throughout the year, provided that installations incorporate appropriate protective measures against the local environmental conditions.

Note: The Tropics are located between 23.5° North and -23.5° South of the equator.

So far, we have conducted calculations to evaluate the solar photovoltaic (PV) potential in 88 locations across Thailand. This analysis provides insights into each city/location's potential for harnessing solar energy through PV installations.

Link: Solar PV potential in Thailand by location

Solar output per kW of installed solar PV by season in Phetchabun

Seasonal solar PV output for Latitude: 16.7839, Longitude: 101.2466 (Phetchabun, Thailand), based on our analysis of 8760 hourly intervals of solar and meteorological data (one whole year) retrieved for that set of coordinates/location from NASA POWER (The Prediction of Worldwide Energy Resources) API:



Ideally tilt fixed solar panels 17° South in Phetchabun, Thailand

To maximize your solar PV system's energy output in Phetchabun, Thailand (Lat/Long 16.7839, 101.2466) throughout the year, you should tilt your panels at an angle of 17° South for fixed panel installations.

As the Earth revolves around the Sun each year, the maximum angle of elevation of the Sun varies by +/- 23.45 degrees from its equinox elevation angle for a particular latitude. Finding the exact optimal angle to maximise solar PV production throughout the year can be challenging, but with careful consideration of historical solar energy and meteorological data for a certain location, it can be done precisely.

We use our own calculation, which incorporates NASA solar and meteorological data for the exact Lat/Long coordinates, to determine the ideal tilt angle of a solar panel that will yield maximum annual solar output. We calculate the optimal angle for each day of the year, taking into account its contribution to the yearly total PV potential at that specific location.

Seasonally adjusted solar panel tilt angles for Phetchabun, Thailand

If you can adjust the tilt angle of your solar PV panels, please refer to the seasonal tilt angles below for optimal solar energy production in Phetchabun, Thailand. As mentioned earlier, for fixed-panel solar PV installations, it is optimal to maintain a 17° South tilt angle throughout the year.

Overall Best Summer Angle	Overall Best Autumn Angle	Overall Best Winter Angle	Overall Best Spring Angle
1° South in Summer	23° South in Autumn	32° South in Winter	10° South in Spring

Our recommendations take into account more than just latitude and Earth's position in its elliptical orbit around the Sun. We also incorporate historical solar and meteorological data from NASA's Prediction of Worldwide Energy Resources (POWER) API to assign a weight to each ideal angle for each day based on its historical contribution to overall solar PV potential during a specific season.

This approach allows us to provide much more accurate recommendations than relying solely on latitude, as it considers unique weather conditions in different locations sharing the same latitude worldwide.

Calculate solar panel row spacing in Phetchabun, Thailand

We've added a feature to calculate minimum solar panel row spacing by location. Enter your panel size and orientation below to get the minimum spacing in Phetchabun, Thailand.

Our calculation method

1. Solar Position:
   We determine the Sun's position on the Winter solstice using the location's latitude and solar declination.
2. Shadow Projection:
   We calculate the shadow length cast by panels using trigonometry, considering panel tilt and the Sun's elevation angle.
3. Minimum Spacing:
   We add the shadow length to the horizontal space occupied by tilted panels.

This approach ensures maximum space efficiency while avoiding shading during critical times, as the Winter solstice represents the worst-case scenario for shadow length.

Topography for solar PV around Phetchabun, Thailand

Topographical Features of the Phetchabun Region

Phetchabun province sits in the heart of Thailand's lower northern region, characterized by a dramatically varied landscape that transitions from mountainous terrain to expansive valleys. The area is dominated by the Phetchabun mountain range, which forms part of the larger Luang Prabang Range extending southward from Laos. These mountains create a natural barrier between Thailand's northern and central plains, with peaks rising to over 1,600 meters above sea level.

The topography features steep-sided valleys carved by numerous rivers and streams, creating a complex network of ridges and hollows. The western portions of the province are particularly mountainous, with dense forest cover and challenging terrain that makes large-scale development difficult. Moving eastward, the landscape gradually becomes more moderate, though still maintaining significant elevation changes and rolling hills.

Between the mountain ranges lie several substantial valleys and plateaus that provide flatter terrain suitable for agriculture and development. The Pasak River valley runs through the central portion of the province, creating fertile lowlands that have been cultivated for generations. These river valleys and their associated flood plains represent some of the most accessible and developable land in the region.

Climate and Environmental Considerations

The mountainous terrain creates distinct microclimates throughout the region, with higher elevations experiencing cooler temperatures and different precipitation patterns than the valleys below. The complex topography influences wind patterns and cloud formation, which can affect weather conditions across relatively short distances.

Dense forest coverage remains extensive throughout much of the mountainous areas, providing important watershed protection and biodiversity habitat. These forested regions experience frequent cloud cover and mist, particularly during certain seasons, which influences the local climate patterns.

Optimal Areas for Large-Scale Solar Development

The most promising locations for large-scale solar photovoltaic installations would be found in the flatter valley areas and plateaus, particularly those with southern exposure and minimal shading from surrounding mountains. The Pasak River valley and similar broad valleys offer relatively level terrain that would minimize grading and construction costs while providing adequate space for extensive solar arrays.

Areas southeast of Phetchabun city, where the terrain begins to flatten toward the central plains, present excellent opportunities for solar development. These locations benefit from being at moderate elevations with good drainage, while avoiding the steeper slopes and dense forest cover of the higher mountain areas. The rolling hills in these areas often provide natural windbreaks while maintaining good solar exposure.

Agricultural areas that have already been cleared and leveled would be particularly suitable, as the land preparation work has largely been completed. Many rice fields and other agricultural areas in the valley bottoms could potentially be adapted for solar use, though careful consideration would need to be given to competing land uses and local food security needs.

The areas closer to existing road networks and electrical infrastructure would be most practical for large-scale development, as the mountainous terrain makes extending utilities and access roads expensive and technically challenging. Locations within reasonable distance of the provincial highway system and existing power transmission lines would significantly reduce project development costs and complexity.

Thailand solar PV Stats as a country

Thailand ranks 26th in the world for cumulative solar PV capacity, with 3,049 total MW's of solar PV installed. This means that 2.90% of Thailand's total energy as a country comes from solar PV (that's 29th in the world). Each year Thailand is generating 44 Watts from solar PV per capita (Thailand ranks 54th in the world for solar PV Watts generated per capita). [source]

Are there incentives for businesses to install solar in Thailand?

Yes, there are several incentives for businesses wanting to install solar energy in Thailand. The Thai government offers a number of tax incentives and subsidies for businesses that install solar energy systems. These include a 30% corporate income tax deduction on the cost of installing solar panels, as well as an exemption from import duties on certain components used in the installation process. Additionally, businesses can benefit from net metering policies which allow them to sell excess electricity generated by their solar system back to the grid at a premium rate. Finally, businesses may also be eligible for grants and other financial assistance from various government agencies and private organizations.

Do you have more up to date information than this on incentives towards solar PV projects in Thailand? Please reach out to us and help us keep this information current. Thanks!
