Araripe, Ceará, Brazil represents an excellent location for year-round solar energy generation. This tropical location enjoys consistent sunlight throughout most of the year, with seasonal variations driven more by wet and dry periods rather than the dramatic temperature and daylight changes seen in temperate regions.

Solar Energy Production Potential

The solar energy output at Araripe demonstrates strong performance across all seasons, with some notable seasonal variations. During summer months, solar panels can be expected to generate 5.50 kWh per day for each kilowatt of installed capacity. This increases to 5.87 kWh/day in autumn, then rises further to 6.32 kWh/day during winter. Spring emerges as the peak solar generation season at this location, delivering an impressive 7.15 kWh per day per kilowatt of installed solar capacity. This makes spring the ideal time for maximum solar energy production at Araripe. For installations using fixed solar panels at this location, the optimal tilt angle is 8 degrees facing north. This angle maximizes total year-round solar energy production by accounting for the sun's path throughout the year and the location's position relative to the equator.

Environmental and Weather Challenges

Several environmental factors at Araripe could potentially impact solar energy production and require careful consideration during installation planning. The tropical climate brings distinct wet and dry seasons, with the wet season presenting the most significant challenge for solar installations. Heavy rainfall during wet periods can reduce solar irradiance reaching the panels and create issues with water accumulation if drainage is inadequate. Additionally, increased humidity during these periods can affect electrical components and connections if not properly protected. Dust accumulation represents another concern, particularly during dry seasons when fine particles can settle on panel surfaces and reduce their efficiency. The semi-arid characteristics of the broader region mean that dust storms or periods of increased airborne particles could periodically affect solar panel performance.

Preventative Measures for Optimal Performance

Several installation strategies can help maximize solar energy production despite these environmental challenges:

• Install panels with adequate drainage systems and slight tilting beyond the optimal 8-degree angle if necessary to prevent water pooling
• Use high-quality weatherproof electrical components and junction boxes rated for tropical conditions
• Implement regular cleaning schedules, particularly important during and after dry seasons when dust accumulation is highest
• Consider automated cleaning systems for larger installations to maintain panel efficiency year-round
• Ensure proper ventilation around panels to prevent moisture buildup and allow for air circulation

Despite these considerations, Araripe's consistent solar energy output throughout the year, peaking at over 7 kWh per day per kilowatt in spring, makes it a highly suitable location for solar energy projects. The tropical location's reliable sunshine and the relatively manageable environmental challenges make it an attractive option for both residential and commercial solar installations.

Note: The Tropics are located between 23.5° North and -23.5° South of the equator.

So far, we have conducted calculations to evaluate the solar photovoltaic (PV) potential in 3161 locations across Brazil. This analysis provides insights into each city/location's potential for harnessing solar energy through PV installations.

Link: Solar PV potential in Brazil by location

Solar output per kW of installed solar PV by season in Araripe

Seasonal solar PV output for Latitude: -7.2072, Longitude: -40.1126 (Araripe, Brazil), based on our analysis of 8760 hourly intervals of solar and meteorological data (one whole year) retrieved for that set of coordinates/location from NASA POWER (The Prediction of Worldwide Energy Resources) API:



Ideally tilt fixed solar panels 8° North in Araripe, Brazil

To maximize your solar PV system's energy output in Araripe, Brazil (Lat/Long -7.2072, -40.1126) throughout the year, you should tilt your panels at an angle of 8° North for fixed panel installations.

As the Earth revolves around the Sun each year, the maximum angle of elevation of the Sun varies by +/- 23.45 degrees from its equinox elevation angle for a particular latitude. Finding the exact optimal angle to maximise solar PV production throughout the year can be challenging, but with careful consideration of historical solar energy and meteorological data for a certain location, it can be done precisely.

We use our own calculation, which incorporates NASA solar and meteorological data for the exact Lat/Long coordinates, to determine the ideal tilt angle of a solar panel that will yield maximum annual solar output. We calculate the optimal angle for each day of the year, taking into account its contribution to the yearly total PV potential at that specific location.

Seasonally adjusted solar panel tilt angles for Araripe, Brazil

If you can adjust the tilt angle of your solar PV panels, please refer to the seasonal tilt angles below for optimal solar energy production in Araripe, Brazil. As mentioned earlier, for fixed-panel solar PV installations, it is optimal to maintain a 8° North tilt angle throughout the year.

Overall Best Summer Angle	Overall Best Autumn Angle	Overall Best Winter Angle	Overall Best Spring Angle
9° South in Summer	13° North in Autumn	23° North in Winter	2° North in Spring

Our recommendations take into account more than just latitude and Earth's position in its elliptical orbit around the Sun. We also incorporate historical solar and meteorological data from NASA's Prediction of Worldwide Energy Resources (POWER) API to assign a weight to each ideal angle for each day based on its historical contribution to overall solar PV potential during a specific season.

This approach allows us to provide much more accurate recommendations than relying solely on latitude, as it considers unique weather conditions in different locations sharing the same latitude worldwide.

Calculate solar panel row spacing in Araripe, Brazil

We've added a feature to calculate minimum solar panel row spacing by location. Enter your panel size and orientation below to get the minimum spacing in Araripe, Brazil.

Our calculation method

1. Solar Position:
   We determine the Sun's position on the Winter solstice using the location's latitude and solar declination.
2. Shadow Projection:
   We calculate the shadow length cast by panels using trigonometry, considering panel tilt and the Sun's elevation angle.
3. Minimum Spacing:
   We add the shadow length to the horizontal space occupied by tilted panels.

This approach ensures maximum space efficiency while avoiding shading during critical times, as the Winter solstice represents the worst-case scenario for shadow length.

Topography for solar PV around Araripe, Brazil

Topographical Features of the Araripe Region

The area around Araripe in northeastern Brazil sits within the distinctive Araripe Plateau, a remarkable geological formation that rises dramatically from the surrounding lowlands of the Caatinga region. This elevated plateau creates a unique landscape characterized by steep escarpments, flat-topped mesas, and deeply incised valleys. The terrain transitions from the relatively flat plateau surface at elevations of approximately 800 to 900 meters above sea level down to the surrounding plains at around 400 to 500 meters elevation. The Araripe Plateau extends across the borders of Ceará, Pernambuco, and Piauí states, forming one of the most significant topographical features in the Brazilian Northeast. The plateau's distinctive layered sedimentary rock formations create natural terraces and cliff faces, while the upper surfaces tend to be relatively level with gentle undulations. These flatter areas on top of the plateau contrast sharply with the more rugged terrain found along the escarpment edges and in the dissected valleys below. The region experiences a semi-arid climate typical of the Caatinga biome, with the elevated areas of the plateau receiving slightly more precipitation than the surrounding lowlands due to orographic effects. The landscape is dotted with seasonal streams and small rivers that have carved narrow valleys through the sedimentary layers over millions of years.

Optimal Areas for Large-Scale Solar Development

The most promising locations for large-scale solar photovoltaic installations in the Araripe region would be found on the relatively flat surfaces of the plateau itself, particularly in areas where the terrain has minimal slope and few natural obstacles. These elevated flat areas offer several advantages including reduced grading requirements, lower construction costs, and minimal shading from surrounding topographical features. The eastern and southeastern portions of the plateau present particularly favorable conditions, where extensive flat to gently rolling terrain provides ample space for solar arrays. These areas benefit from their elevated position above the surrounding landscape, which helps minimize atmospheric interference and provides excellent exposure to solar radiation throughout the day. Areas slightly removed from the steepest escarpment edges would be ideal, as they combine the benefits of the plateau's elevation with reduced exposure to potentially problematic wind patterns that can occur near cliff faces. The sedimentary bedrock underlying much of the plateau provides stable foundation conditions for solar installations, though detailed geotechnical analysis would be necessary for any specific site. The lower elevation areas surrounding the base of the plateau, while flatter in some locations, may be less optimal due to occasional flooding during seasonal rains and the presence of more vegetation that would require clearing. However, some of these areas, particularly those with good drainage and minimal vegetation, could still serve as viable alternatives for solar development, especially if transmission infrastructure access is more favorable at lower elevations. Transportation access and proximity to existing electrical infrastructure would ultimately play crucial roles in determining the most economically viable locations within this topographically diverse region.

Brazil solar PV Stats as a country

Brazil ranks 13th in the world for cumulative solar PV capacity, with 13,708 total MW's of solar PV installed. This means that 2.50% of Brazil's total energy as a country comes from solar PV (that's 31st in the world). Each year Brazil is generating 64 Watts from solar PV per capita (Brazil ranks 47th in the world for solar PV Watts generated per capita). [source]

Are there incentives for businesses to install solar in Brazil?

Yes, there are several incentives for businesses wanting to install solar energy in Brazil. The Brazilian government offers a range of tax credits and other financial incentives to encourage the adoption of renewable energy sources such as solar power. These include reduced import taxes on solar equipment, accelerated depreciation of investments in renewable energy projects, and preferential financing from public banks. Additionally, some states offer additional incentives such as subsidies or grants for businesses that install solar systems.

Do you have more up to date information than this on incentives towards solar PV projects in Brazil? Please reach out to us and help us keep this information current. Thanks!
