Solar Energy Potential in Campo Belo, Minas Gerais, Brazil

Campo Belo, Minas Gerais, Brazil, situated at latitude -20.9262 and longitude -45.2372, offers promising conditions for solar energy generation throughout the year. This tropical location benefits from relatively consistent sunlight patterns that make it suitable for photovoltaic (PV) installations. The seasonal solar production data reveals a balanced output across the year. During summer months, solar panels can generate approximately 6.47 kWh per day for each kilowatt installed, representing the peak production period. Spring follows with a solid 6.10 kWh/day, while autumn yields 5.86 kWh/day. Winter shows the lowest but still substantial output at 5.28 kWh/day per kilowatt installed.

Seasonal Variations and Optimal Production

What makes Campo Belo particularly favorable for solar energy is the relatively small difference between peak summer production and minimum winter output—only about 1.19 kWh/day per kilowatt. This consistency means that solar installations remain productive year-round, unlike locations at higher latitudes that experience dramatic seasonal fluctuations. For fixed panel installations in Campo Belo, Minas Gerais, the ideal angle to maximize year-round energy production is 20 degrees facing North. This orientation optimizes the panels' exposure to the sun's path throughout the year, accounting for the site's position in the Southern Hemisphere.

Environmental and Weather Considerations

Several environmental factors could affect solar production in Campo Belo:

• Seasonal rainfall, particularly during the wet season, may temporarily reduce solar output due to cloud cover
• Dust accumulation on panels, common in tropical environments, can gradually decrease efficiency
• Occasional high temperatures may slightly reduce panel efficiency during the hottest periods

Preventative Measures

To maximize energy production despite these challenges, several preventative measures are recommended: Installing panels with a self-cleaning tilt angle (the recommended 20 degrees) helps rainwater naturally wash away dust and debris. Additionally, implementing a regular cleaning schedule during dry periods is advisable to maintain optimal performance. Using high-quality panels with temperature-tolerant specifications will help mitigate efficiency losses during hot weather. Installing panels with sufficient airflow beneath them can also help dissipate heat and maintain better performance. For installations concerned about seasonal variations, slightly adjusting the panel angle twice yearly (steeper during winter, flatter during summer) could further optimize production, though the consistent year-round output may not justify this added complexity for most installations. Overall, Campo Belo presents favorable conditions for solar PV installations with relatively minor seasonal variations, making it a suitable location for reliable solar energy production throughout the year.

Note: The Tropics are located between 23.5° North and -23.5° South of the equator.

So far, we have conducted calculations to evaluate the solar photovoltaic (PV) potential in 3161 locations across Brazil. This analysis provides insights into each city/location's potential for harnessing solar energy through PV installations.

Link: Solar PV potential in Brazil by location

Solar output per kW of installed solar PV by season in Campo Belo

Seasonal solar PV output for Latitude: -20.9262, Longitude: -45.2372 (Campo Belo, Brazil), based on our analysis of 8760 hourly intervals of solar and meteorological data (one whole year) retrieved for that set of coordinates/location from NASA POWER (The Prediction of Worldwide Energy Resources) API:



Ideally tilt fixed solar panels 20° North in Campo Belo, Brazil

To maximize your solar PV system's energy output in Campo Belo, Brazil (Lat/Long -20.9262, -45.2372) throughout the year, you should tilt your panels at an angle of 20° North for fixed panel installations.

As the Earth revolves around the Sun each year, the maximum angle of elevation of the Sun varies by +/- 23.45 degrees from its equinox elevation angle for a particular latitude. Finding the exact optimal angle to maximise solar PV production throughout the year can be challenging, but with careful consideration of historical solar energy and meteorological data for a certain location, it can be done precisely.

We use our own calculation, which incorporates NASA solar and meteorological data for the exact Lat/Long coordinates, to determine the ideal tilt angle of a solar panel that will yield maximum annual solar output. We calculate the optimal angle for each day of the year, taking into account its contribution to the yearly total PV potential at that specific location.

Seasonally adjusted solar panel tilt angles for Campo Belo, Brazil

If you can adjust the tilt angle of your solar PV panels, please refer to the seasonal tilt angles below for optimal solar energy production in Campo Belo, Brazil. As mentioned earlier, for fixed-panel solar PV installations, it is optimal to maintain a 20° North tilt angle throughout the year.

Overall Best Summer Angle	Overall Best Autumn Angle	Overall Best Winter Angle	Overall Best Spring Angle
5° North in Summer	27° North in Autumn	36° North in Winter	15° North in Spring

Our recommendations take into account more than just latitude and Earth's position in its elliptical orbit around the Sun. We also incorporate historical solar and meteorological data from NASA's Prediction of Worldwide Energy Resources (POWER) API to assign a weight to each ideal angle for each day based on its historical contribution to overall solar PV potential during a specific season.

This approach allows us to provide much more accurate recommendations than relying solely on latitude, as it considers unique weather conditions in different locations sharing the same latitude worldwide.

Calculate solar panel row spacing in Campo Belo, Brazil

We've added a feature to calculate minimum solar panel row spacing by location. Enter your panel size and orientation below to get the minimum spacing in Campo Belo, Brazil.

Our calculation method

1. Solar Position:
   We determine the Sun's position on the Winter solstice using the location's latitude and solar declination.
2. Shadow Projection:
   We calculate the shadow length cast by panels using trigonometry, considering panel tilt and the Sun's elevation angle.
3. Minimum Spacing:
   We add the shadow length to the horizontal space occupied by tilted panels.

This approach ensures maximum space efficiency while avoiding shading during critical times, as the Winter solstice represents the worst-case scenario for shadow length.

Topography for solar PV around Campo Belo, Brazil

Campo Belo is situated in the southeastern region of Brazil, in the state of Minas Gerais. The topography of the area is characterized by rolling hills and plateaus typical of the Brazilian highlands. The region sits at an elevation of approximately 945 meters (3,100 feet) above sea level, creating a varied landscape with gentle undulations rather than dramatic mountain ranges. The surrounding terrain features a mix of open fields and scattered vegetation, with the land gradually sloping in various directions. To the east and northeast, the landscape becomes more rugged as it transitions toward the mountainous regions that form part of the Serra da Mantiqueira mountain range, though these major elevations are some distance from Campo Belo itself.

Hydrography and Its Impact on Topography

Several water bodies influence the local topography, including the Rio Grande river basin to the south. These waterways have carved shallow valleys throughout the region over geological time, creating natural divisions in the landscape. The drainage patterns have shaped the gentle hills that characterize much of the area around Campo Belo.

Vegetation and Land Use

The natural vegetation of the region has been significantly altered by human activity, with much of the original Atlantic Forest and Cerrado (tropical savanna) having been cleared for agricultural purposes. Currently, the landscape consists of a patchwork of farmland, pastures, and remnant forest patches. This agricultural development has further smoothed some of the natural contours of the land.

Optimal Areas for Solar PV Development

For large-scale solar photovoltaic installations, the gently sloping areas to the west and southwest of Campo Belo present the most favorable conditions. These regions offer several advantages: The western plains have fewer obstructions from vegetation and feature expansive open areas with consistent, moderate slopes facing northward (optimal for the Southern Hemisphere). These areas receive consistent solar exposure throughout the day without significant shadowing from topographical features. The southwestern sector, extending toward the municipalities of Santana do Jacaré and Cana Verde, contains elevated plateaus with minimal slope variations. These plateaus provide excellent sites for solar farms as they require less grading and preparation work. Areas to avoid include the more densely vegetated eastern sections where remaining forest fragments create irregular shadowing patterns, and the lower-lying areas near water bodies where morning fog may be more prevalent, potentially reducing early day solar efficiency. The northwestern corridor also shows promise for solar development, featuring gradually rising terrain with good drainage characteristics. This area has predominantly been converted to agricultural use, meaning land acquisition might be more straightforward with fewer natural habitat concerns compared to areas with remnant native vegetation. The relatively flat terrain throughout much of the region means that construction challenges are minimized compared to more mountainous regions elsewhere in Minas Gerais, making Campo Belo and its surroundings particularly suitable for large-scale solar energy development from a topographical perspective.

Brazil solar PV Stats as a country

Brazil ranks 13th in the world for cumulative solar PV capacity, with 13,708 total MW's of solar PV installed. This means that 2.50% of Brazil's total energy as a country comes from solar PV (that's 31st in the world). Each year Brazil is generating 64 Watts from solar PV per capita (Brazil ranks 47th in the world for solar PV Watts generated per capita). [source]

Are there incentives for businesses to install solar in Brazil?

Yes, there are several incentives for businesses wanting to install solar energy in Brazil. The Brazilian government offers a range of tax credits and other financial incentives to encourage the adoption of renewable energy sources such as solar power. These include reduced import taxes on solar equipment, accelerated depreciation of investments in renewable energy projects, and preferential financing from public banks. Additionally, some states offer additional incentives such as subsidies or grants for businesses that install solar systems.

Do you have more up to date information than this on incentives towards solar PV projects in Brazil? Please reach out to us and help us keep this information current. Thanks!
