Location estimate

Dina

Azad Jammu and Kashmir(POK) · Pakistan

Approximate location reference—not a rooftop, property or survey point.

Seasonal average-day estimates

Selected capacity 1 kWp

Showing the original estimates at 1 kWp. JavaScript is needed only to change capacity; source values and panel settings remain available below.

Changing capacity rescales my existing estimates. It does not recalculate their orientation, shading, equipment or loss assumptions.

Estimated average daily electricity for 1 kWp, in kWh/day, averaged over each season.

Summer

6.81

kWh/day

Autumn

4.93

kWh/day

Winter

3.68

kWh/day

Spring

6.37

kWh/day

Shared scale: 0–7.00 kWh/day.

I apply the same capacity factor to every season, so their proportions stay unchanged. The shared visual scale adjusts with capacity. To compare different system sizes, use the displayed kWh/day values.

This is illustrative scaling, not a site-specific production prediction.

Source basis and scaling limits

Original seasonal average-day estimates for Dina, in kWh/kWp/day.

I calculate the scaled results from the original seasonal values and round the final energy results to two decimal places. Exceptionally large values may appear in approximate scientific notation; the full results, rounded to two decimal places, remain available here.

Original source values and selected-capacity calculation
SeasonRecorded kWh/kWp/dayExact selected-capacity result · kWh/day
Summer 6.81 6.81 × 1 kWp = 6.81 kWh/day
Autumn 4.93 4.93 × 1 kWp = 4.93 kWh/day
Winter 3.68 3.68 × 1 kWp = 3.68 kWh/day
Spring 6.37 6.37 × 1 kWp = 6.37 kWh/day

Ordinary calculations wrap onto two lines. Exceptionally long calculations can be scrolled within their labelled region.

Full results rounded to two decimal places

These preserve every whole-number digit. Exceptionally long values can be scrolled horizontally inside each labelled result.

Summer · kWh/day
6.81
Autumn · kWh/day
4.93
Winter · kWh/day
3.68
Spring · kWh/day
6.37

The original values remain available without JavaScript. Energy always uses kWh/day, including when capacity is entered in MWp. Changing units preserves the same physical capacity.

These are seasonal average-day estimates, not annual totals or installation sizing. Changing capacity does not revisit the assumptions used in my original estimates.

Detailed site analysisExplore historical generation and system configurations for your own project or your clients in the profileSOLAR app.

Year-round panel setup

Schematic catalogue setting — Year-round fixed panel setup: tilt 29 degrees above horizontal; facing South. Direction is illustrative; exact azimuth not recorded.NESW
Year-round fixed panel setup · schematic
Tilt from horizontal
29°
Facing direction
South

Catalogue direction; exact azimuth not recorded. The facing direction is illustrative.

Suggested seasonal tilts

Tilt from horizontal · facing direction

Summer
Jun, Jul, Aug
16°South
Autumn
Sep, Oct, Nov
38°South
Winter
Dec, Jan, Feb
48°South
Spring
Mar, Apr, May
26°South

The seasonal electricity figures do not model gains from switching between these settings.

About this orientation

This schematic shows the year-round panel tilt and facing direction for Dina, Azad Jammu and Kashmir(POK), Pakistan.

For the year-round panel tilt, I used a simplified solar-noon calculation. This gives a broad starting point for considering a fixed panel angle at the location.

I weighted the daily angles by their share of estimated output. Read how I calculated panel tilt.

The panel shows tilt above horizontal on a fixed compass. North stays at the upper right in this projected view. Schematic only—not roof geometry, an installation drawing or a selected practical design.

Year-round and seasonal panel angles are separate estimates. Changing capacity rescales the existing energy values; it does not recalculate output for a different angle or facing direction.

Seasonal orientation diagrams

These show the separate seasonal settings above. Changing capacity does not change these angles or recalculate energy for a different orientation.

Summer

Schematic catalogue setting — Summer panel setup: tilt 16 degrees above horizontal; facing South. Direction is illustrative; exact azimuth not recorded.NESW
Summer panel setup · schematic

16° tilt · South

Illustrative direction; exact azimuth not recorded.

Autumn

Schematic catalogue setting — Autumn panel setup: tilt 38 degrees above horizontal; facing South. Direction is illustrative; exact azimuth not recorded.NESW
Autumn panel setup · schematic

38° tilt · South

Illustrative direction; exact azimuth not recorded.

Winter

Schematic catalogue setting — Winter panel setup: tilt 48 degrees above horizontal; facing South. Direction is illustrative; exact azimuth not recorded.NESW
Winter panel setup · schematic

48° tilt · South

Illustrative direction; exact azimuth not recorded.

Spring

Schematic catalogue setting — Spring panel setup: tilt 26 degrees above horizontal; facing South. Direction is illustrative; exact azimuth not recorded.NESW
Spring panel setup · schematic

26° tilt · South

Illustrative direction; exact azimuth not recorded.

Historical hourly-by-season solar output chart for Dina, Pakistan. View larger
Original chart units: hourly average electricity output in kWh per kW of installed solar PV.

Hourly electricity pattern for Dina, Pakistan

Hourly profiles by season — Dina, Pakistan · 2021

This chart shows how average electricity output varies through the hours of the day in each season. I have kept its original per-capacity basis: changing the capacity slider does not change this chart.

2021 is the method’s reference year, not verified year coverage for every point in this historical chart.

The cards above show seasonal average-day energy; this chart shows the hourly pattern. View the year-round panel setup.

Historical hourly chart

Hourly profiles by season — Dina, Pakistan · 2021

Swipe to pan, or focus the chart and use arrow keys.

Original chart units: hourly average electricity output in kWh per kW of installed solar PV.

This chart shows how average electricity output varies through the hours of the day in each season. I have kept its original per-capacity basis: changing the capacity slider does not change this chart.

The cards above show seasonal average-day energy; this chart shows the hourly pattern.

2021 is the method’s reference year, not verified year coverage for every plotted point.

Enlargement is limited to the original image resolution.

Row-spacing planning

Planning solar-panel row spacing in Dina

Explore the space between parallel panel rows at one assumed winter-solstice solar-noon position.

Example: 2 m panel surface length, recorded year-round tilt and no added margin. Enable JavaScript to change these inputs.

Row pitch including margin

≈ 3.21 m

Proportional side viewDesign sun: ≈ 33.52° above horizontal
Row 1 Row 2 Clear gap Added margin: 0 m Row pitch including margin
  • Sunlight ray
  • First row’s ground shadow
  • Shadow endpoint
Calculated clear gap
≈ 1.46 m
Added margin
≈ 0 m
Gap including margin
≈ 1.46 m
Panel horizontal footprint
≈ 1.75 m
Panel vertical rise
≈ 0.97 m
Pitch before margin
≈ 3.21 m

Simplified level ground, equator-facing cross-section. Approximate Northern Hemisphere winter solstice at solar noon (day 355). The separate recorded facing direction is not an input.

One sun position, not a complete site-shading assessment. A geometric zero gap does not establish adequate installation, access or maintenance clearance.

Detailed inputs and unrounded results

More digits retain calculation precision; they do not imply greater model accuracy. Pitch including margin is pitch before margin plus the added margin, including when that margin is zero.

Panel surface length
2 m
Tilt up from horizontal
29°
Added margin
0 m
Latitude from the catalogue
33.034600000000000000° (Northern Hemisphere)
Panel horizontal footprint
1.7492394142787915 m
Panel vertical rise
0.9696192404926741 m
Calculated clear gap
1.4640676661530398 m
Pitch before margin
3.2133070804318313 m
Gap including margin
1.4640676661530398 m
Row pitch including margin
3.2133070804318313 m
Design solar elevation
33.51561715318635°
How this spacing estimate is calculated

I calculate this example at approximate winter solstice and solar noon for the location’s hemisphere. Tilt is measured up from horizontal and panel length is measured along the tilted module surface.

δ = 23.45° × sin(360° × (day − 81) ÷ 365); α = asin(sin(latitude) × sin(δ) + cos(latitude) × cos(δ)).

Rise = length × sin(tilt). Footprint = length × cos(tilt). Clear gap = rise ÷ tan(α). Row pitch = footprint + clear gap. The optional margin is added to the gap and pitch.

The calculated clear gap is the horizontal distance from the first panel’s high edge to its shadow endpoint. Any added margin then extends to the next row. Pitch is measured between corresponding leading edges, not just across the clear gap. The target is no geometric shadow at that one simplified solar-noon design instant.

The cross-section assumes parallel, equator-facing rows and a solar-noon ray perpendicular to them. The method ignores azimuth error and does not use the separate facing direction recorded for this location.

Terrain, mounting height, module thickness, obstructions, structural loads and regulations are outside this simplified geometry. A qualified designer should verify a real installation.

Detailed site analysisExplore historical generation and system configurations for your own project or your clients in the profileSOLAR app.

Solar context for Dina

Read this location context alongside the calculation method and limitations; installation guidance is not a site-specific assessment.

<h3>Solar Energy Potential in Dina, Pakistan</h3>

Read the full article

Dina, Pakistan, located in the Northern Sub Tropics at coordinates 33.0346, 73.6095, offers generally favorable conditions for solar PV energy generation, though with significant seasonal variations. The location experiences strong solar production potential throughout the year, with particularly impressive output during summer months. The seasonal energy production from solar panels in Dina shows a clear pattern. Summer stands out as the most productive season, generating 6.81kWh per day for each kilowatt of installed capacity. Spring follows closely behind with 6.37kWh/day. Production decreases noticeably during autumn to 4.93kWh/day, while winter sees the lowest output at 3.68kWh/day per kilowatt installed. <h3>Optimal Installation Angle</h3> For maximizing year-round solar production in Dina, fixed solar panels should be installed at a tilt angle of 29 degrees facing South. This specific angle has been calculated to capture the maximum possible solar energy throughout the year, accounting for the Earth's elliptical orbit and Dina's geographical position in the Northern Sub Tropics. <h3>Environmental and Weather Considerations</h3> Several environmental factors could potentially impact solar production in Dina: <ul> <li>Dust and air pollution: The region can experience dust storms and urban pollution that may accumulate on panels, reducing efficiency</li> <li>Seasonal monsoon rains: Heavy precipitation during monsoon season can temporarily reduce solar output</li> <li>Occasional haze: Atmospheric haze, particularly during certain seasons, may diffuse sunlight and slightly reduce panel efficiency</li> </ul> <h3>Preventative Measures</h3> To maximize solar energy production despite these challenges, several preventative measures are recommended: <ul> <li>Regular cleaning schedule: Implement a consistent panel cleaning routine, particularly before and after dust storms</li> <li>Quality inverters: Install inverters designed to perform efficiently even in high-temperature conditions</li> <li>Elevated mounting: Consider raising panels slightly higher than standard installations to reduce dust accumulation</li> <li>Anti-soiling coatings: Apply specialized coatings that help panels shed dust and dirt more effectively</li> </ul> With proper installation at the recommended 29-degree south-facing angle and appropriate maintenance measures, solar PV systems in Dina can capitalize on the region's strong solar resources, particularly during the highly productive summer and spring months, while minimizing potential losses during the less productive autumn and winter periods.

Topography around Dina

These landscape descriptions provide general context. The calculations do not model terrain, obstructions, shading or property suitability.

The terrain around Dina, Pakistan presents a diverse topographic profile characterized by both flat plains and rolling hills. Located in the Jhelum District of Punjab province, Dina sits in a transitional zone between the fertile plains of Punjab to the south and the foothills of the Himalayan mountain range to the north.

Read the full topography description

<h3>Topographical Features</h3> The immediate vicinity of Dina features gently undulating landscape with moderate elevation changes. As one moves northward from Dina, the terrain gradually becomes more pronounced with increasing elevation, eventually developing into the Pothohar Plateau region. This plateau is characterized by numerous ravines, small plateaus, and isolated hills that create a varied landscape. To the south and southeast of Dina, the land flattens considerably as it transitions into the alluvial plains of Punjab. These areas benefit from rich soil deposited by the Jhelum River, which flows approximately 10 kilometers east of Dina. The river valley creates a notable depression in the otherwise moderately elevated region. The western approaches to Dina feature a mix of flat areas interspersed with occasional hills and ridges. These natural formations create a patchwork of different elevations and slopes throughout the region. <h3>Solar PV Potential Areas</h3> For large-scale solar photovoltaic installations, several nearby areas offer promising conditions based on their topographical characteristics: The southern plains extending from Dina toward Sohawa present extensive flat terrain with minimal shading concerns. These areas provide ample space for large solar arrays without requiring significant land modification. The relatively unobstructed horizon in these southern plains minimizes early morning and late afternoon shading issues. Elevated plateaus to the northwest of Dina offer another viable option for solar development. These plateaus typically feature level surfaces at higher elevations, potentially reducing dust accumulation and providing clearer atmospheric conditions. The natural elevation can minimize shading from surrounding terrain features. The gently sloping areas southwest of Dina toward Domeli also merit consideration. These zones offer a compromise between completely flat terrain and slightly elevated positions, potentially optimizing exposure while maintaining ease of construction and maintenance access. Areas to avoid include the more deeply cut ravines and valleys to the north, where shading from surrounding hills would significantly reduce solar exposure. Similarly, locations immediately adjacent to the Jhelum River should be avoided due to potential flooding risks and higher humidity levels that might affect equipment longevity. The most optimal areas would be those combining flat or gently sloping terrain with proximity to existing infrastructure such as roads and transmission lines, which are relatively well-developed in the vicinity of Dina due to its location along the Grand Trunk Road corridor connecting Islamabad and Lahore.

Technical location reference

Approximate map point used for Dina, Pakistan

This coordinate is the calculation reference for Dina, Pakistan. Extra decimal places do not make it a rooftop, property or survey point.

Coordinates and precision
Map coordinate
33.034600000000000000, 73.609500000000000000
Originally displayed coordinate
lat33.0346 / long73.6095

How the estimate works

How this Dina estimate was calculated

Here is how I calculated the location estimate for Dina, Pakistan.

Read how all Location estimates work

Source and scope

I calculated these location estimates using hourly NASA POWER solar-resource data, with 2021 as the reference year. The seasonal figures show estimated daily electricity production averaged over each season, on a common panel-capacity basis.

The figures are calculated estimates, not measured output or a new NASA request while you browse.

Reference period and source details

The reference year describes the intended input period; complete source-year coverage is not established for every historical result. Read the technical questions about source data and downloads.

NASA POWER project reference

The data was obtained from National Aeronautics and Space Administration (NASA) Langley Research Center's Prediction Of Worldwide Energy Resources (POWER) project funded through the NASA Earth Science Division.

This source reference does not imply NASA endorsement.

Use the result carefully

What this Dina Location estimate includes and leaves out

Use the Dina figures for broad location context, with the following boundaries in mind.

  • These catalogue estimates are informational; they do not establish a site-specific production result.
  • The location is an approximate reference, not a property, rooftop or survey coordinate.
  • The energy figures support broad location comparisons; they are not a generation guarantee or detailed system design.
  • The seasonal cards show average-day energy. An hourly chart, where available, shows a different view of the daily pattern.
  • Distance and clearance between rows require panel dimensions, mounting height, terrain, acceptable shading and a project-specific design.
