Solar PV Analysis of Sheffield, United Kingdom
Sheffield, United Kingdom, situated at a latitude of 53.381129 and longitude of -1.470085, offers a suitable environment for solar power generation throughout the year. The average energy production per kW of installed solar capacity varies across seasons: 5.09 kWh/day in Summer, 2.08 kWh/day in Autumn, 0.96 kWh/day in Winter, and 4.27 kWh/day in Spring.
During summer months, Sheffield experiences the highest energy generation due to longer daylight hours and increased sunlight intensity. Conversely, winter months yield the lowest energy output as a result of shorter days and reduced sunlight exposure caused by increased cloud cover.
Certain weather conditions prevalent in Sheffield may pose challenges to solar power generation efficiency. Heavy rain or snowfall can obstruct direct sunlight access while strong winds have the potential to damage panels or other components associated with a solar PV system.
To optimize energy production from solar installations in Sheffield's climate, it is recommended that fixed panels be tilted at an angle of 45 degrees facing southward to maximize sun exposure throughout the year.
When planning a solar PV installation in Sheffield or similar locations within the Northern Temperate Zone, it is crucial to consider these environmental factors and implement preventative measures such as durable panel materials and secure mounting systems to ensure greater energy production efficiency despite local weather challenges.
Note: The Northern Temperate Zone extends from 35° latitude North up to 66.5° latitude.
So far, we have conducted calculations to evaluate the solar photovoltaic (PV) potential in 756 locations across United Kingdom. This analysis provides insights into each city/location's potential for harnessing solar energy through PV installations.
Link: Solar PV potential in United Kingdom by location
Solar output per kW of installed solar PV by season in Sheffield
Seasonal solar PV output for Latitude: 53.381129, Longitude: -1.470085 (Sheffield, United Kingdom), based on our analysis of 8760 hourly intervals of solar and meteorological data (one whole year) retrieved for that set of coordinates/location from NASA POWER (The Prediction of Worldwide Energy Resources) API:
Ideally tilt fixed solar panels 45° South in Sheffield, United Kingdom
To maximize your solar PV system's energy output in Sheffield, United Kingdom (Lat/Long 53.381129, -1.470085) throughout the year, you should tilt your panels at an angle of 45° South for fixed panel installations.
As the Earth revolves around the Sun each year, the maximum angle of elevation of the Sun varies by +/- 23.45 degrees from its equinox elevation angle for a particular latitude. Finding the exact optimal angle to maximise solar PV production throughout the year can be challenging, but with careful consideration of historical solar energy and meteorological data for a certain location, it can be done precisely.
We use our own calculation, which incorporates NASA solar and meteorological data for the exact Lat/Long coordinates, to determine the ideal tilt angle of a solar panel that will yield maximum annual solar output. We calculate the optimal angle for each day of the year, taking into account its contribution to the yearly total PV potential at that specific location.
Seasonally adjusted solar panel tilt angles for Sheffield, United Kingdom
If you can adjust the tilt angle of your solar PV panels, please refer to the seasonal tilt angles below for optimal solar energy production in Sheffield, United Kingdom. As mentioned earlier, for fixed-panel solar PV installations, it is optimal to maintain a 45° South tilt angle throughout the year.
| Overall Best Summer Angle | Overall Best Autumn Angle | Overall Best Winter Angle | Overall Best Spring Angle |
|---|---|---|---|
| 37° South in Summer | 56° South in Autumn | 67° South in Winter | 45° South in Spring |
Our recommendations take into account more than just latitude and Earth's position in its elliptical orbit around the Sun. We also incorporate historical solar and meteorological data from NASA's Prediction of Worldwide Energy Resources (POWER) API to assign a weight to each ideal angle for each day based on its historical contribution to overall solar PV potential during a specific season.
This approach allows us to provide much more accurate recommendations than relying solely on latitude, as it considers unique weather conditions in different locations sharing the same latitude worldwide.
Calculate solar panel row spacing in Sheffield, United Kingdom
We've added a feature to calculate minimum solar panel row spacing by location. Enter your panel size and orientation below to get the minimum spacing in Sheffield, United Kingdom.
Our calculation method
- Solar Position:
We determine the Sun's position on the Winter solstice using the location's latitude and solar declination. - Shadow Projection:
We calculate the shadow length cast by panels using trigonometry, considering panel tilt and the Sun's elevation angle. - Minimum Spacing:
We add the shadow length to the horizontal space occupied by tilted panels.
This approach ensures maximum space efficiency while avoiding shading during critical times, as the Winter solstice represents the worst-case scenario for shadow length.
Topography for solar PV around Sheffield, United Kingdom
The topography around Sheffield, United Kingdom is generally hilly and mountainous. Areas to the north and east of the city are particularly hilly, with some peaks reaching heights of over 500m above sea level. To the south and west of the city there is a more gentle rolling landscape with hills that are lower in elevation than those to the north and east. The most suitable areas for large-scale solar PV installations would be on flat or gently sloping land away from trees or other obstructions such as buildings which could cast shadows on panels. Some good options near Sheffield include open farmland to the south and west of the city, where there is plenty of space for large arrays of solar panels.
United Kingdom solar PV Stats as a country
United Kingdom ranks 14th in the world for cumulative solar PV capacity, with 13,689 total MW's of solar PV installed. This means that 4.00% of United Kingdom's total energy as a country comes from solar PV (that's 20th in the world). Each year United Kingdom is generating 203 Watts from solar PV per capita (United Kingdom ranks 25th in the world for solar PV Watts generated per capita). [source]
Are there incentives for businesses to install solar in United Kingdom?
Yes, there are several incentives for businesses wanting to install solar energy in the United Kingdom. The UK government offers a Feed-in Tariff (FiT) scheme which pays businesses for every unit of electricity they generate from their solar panels. Additionally, businesses may be eligible for tax reliefs such as Enhanced Capital Allowances and Renewable Heat Incentives. Finally, some local authorities offer grants or other financial support to help businesses with the cost of installing solar energy systems.
Do you have more up to date information than this on incentives towards solar PV projects in United Kingdom? Please reach out to us and help us keep this information current. Thanks!
